ANDROID SYSTEM PLAYER
SATELLITE GPS SYNC SYSTEM FOR FORD
Description: Available models: Cmax, Ecosport, Edge, Escape, Escort, Explorer, F150,Fiesta, Figo, Focus, Fusion, Ka, Kuga, Mondeo, Mustang, Ranger, Smax, Taurus,Tourneo, TransitBasic hardwareCPU ProcessorTS18, 8-c···
HOT LINE:
+86-13927476268
- Product Details
Available models: Cmax, Ecosport, Edge, Escape, Escort, Explorer, F150,Fiesta, Figo, Focus, Fusion, Ka, Kuga, Mondeo, Mustang, Ranger, Smax, Taurus,Tourneo, Transit
| Basic hardware | CPU Processor | TS18, 8-core processor, 1.8GHz-2.5GHZ |
| RAM & ROM | 2GB RAM 32GB | |
| OS | Android 10.0 | |
| Audio Codec | I2S/PCM2x/AC97/OWA Out | |
| GPU | Mali 400 MP2,Supports OpenGL ES 2.0/OpenVG 1.1 standard | |
| Extended Memory | 3 USB,support up to 500GB on-to-go, 2 SD/TF support 64GB on-to-go | |
| Graphic Capacity | Support users control for contrast, brightness and colors | |
| Language | Multi-language OSD | |
| Display | Capacity | Full multi-point capacitive touch screen |
| Split screen | 3 split screen displays synchronized | |
| Size | 9"/10" 16:9 digital HD LED screen; Resolution: 1024*600 Pixel | |
| Touch screen | 2.5D capacitive touch screen Tempered glass | |
| GPS | Receiver:L1 (1575.42MHz), C/A code (1.023MHz),Sensitivity: -158dBm,Ultra low power consumption as 40nm LP | |
| Wireless Internet | Built-in WIFI on board /802.11 b/g/n; Support 3G/4G via Dongle | |
| FM Radio | FM tuning range: 87.5 to 108.0MHz (Worldwide) | |
| Preset Stationss:30 ; Various radio regions for settings | ||
| Amplifier | Built-in DSP digital amplifier | with professional EQ, simple configuration |
| Voice command and Link | Built-in wireless carplay | built-in wireless android auto |
| Bluetooth | Bluetooth V4.0, Support hand-free talk, phonebook download, contact search, A2DP Music transmit | |
| 4G LTE COMM (optional) | Built-in 4G LTE module on-board (optional), Bands supported: TD-SCDMA/CDMA 1x/EV-DO/GSM/EDGE：900MHz/1800MHz/1900MHz WCDMA：B1/B2/B5/B8 TDD-LTE：B38/B39/B40/B41 FDD_LTE：B1/B3 | |
| Multi-media Player Ability | Video | Format :AVI, H.264, VC-1, MPEG-2, MPEG-4, DIVD, DIVX, Real8, 9, 10, RM, RMVB, FLV, MP4, M4V, VOB, WMV, 3GP, MKV,support 720P & and 1080P video sources,1080p 30 fps |
| Audio | Format : MP3, WMA, FLAC, AAC, WAV,APE, OGG, MP2, 3GP, MA4 | |
| With Audio DSP, 10-band EQ control, integrated DAC, 5.1-channel & Stereo output | ||
| Picture | JPG, BMP, GIF, PNG photos preview, zoom, rotate, slide | |
| eBook | PDF, TXT, WORD, EXCEL, POWERPOINT | |
| Video Output | 4-lane MIPI DSI 1080P @60fps, HDMI output | |
| Video Input | 4-lane MIPI/13 MP | |
| Audio Output | 5.1-Channel 0.25WL | |
| Connect | Mirrorlink for android & Airplay for iPhones/iPods; Hi-Car for auto-pilot cars | |
| More extra functions | Support: DSP amplifier, 4X45W; AUX-INPUT; Rear reversing camera; Front DVR camera; Solar-powered TPMS, Canbus;OBD2, DAB+;360 birdeye camera system; wireless phone charger | |
| Temperature | Work: -20°C - 75°C; | Storage: -30°C - 85°C |
| Humidity | Work: 45% -80% | Storage:30% - 90% |
| Power Consumption | Work: 3W | Standby: <20mW |
